Model no

TMF56A

TMF64A1

TMF64A2

TMF64B

TMF64C

TMF65C

TMF63B

TMF56b

Current pressure

<0.8PM

0.1-0.6MPa

0.1-0.6MPa

0.1-0.6MPa

0.1-0.6MPa

0.1-0.6MPa

0.1-0.6MPa

0.1-0.6MPa

Suited temperature

1.80⁰C

5-45⁰C

5-45⁰C

5-45⁰C

5-45⁰C

5-45⁰C

5-45⁰C

5-45⁰C

Max watereatment capacity

4.5t/h

4.5t/h

4.5t/h

2t/h

2t/h

2t/h

4.5t/h

2t/h

Suited vessel diameter

Soften

Φ150-300 Φ

(6”-12”)

Φ150-450 Φ

(6”-18”)

Φ150-450 Φ

(6”-18”)

Φ150-450 Φ

(6”-18”)

Φ150-450 Φ

(6”-18”)

Φ150-450 Φ

(6”-12”)

Φ150-450 Φ

(6”-18”)

Φ150-300 Φ

(6”-12”)

Filter

Φ150-250 Φ

(6”-10”)

Φ150-300 Φ

(6”-12”)

Φ150-250 Φ

(6”-10”)

Base

2.5”-8NPSM

2.5”-8NPSM

2.5”-8NPSM

2.5”-8NPSM

2.5”-8NPSM

2.5”-8NPSM

2.5”-8NPSM

2.5”-8NPSM

Outlet/Inlet(Female)

1”F

1”F

1”F

¾”F

¾”F

¾”F

1”M

¾”-1/2”F

Drain(Female)

1”F

½”M

½”M

½”M

3/8”M

½”M

½”M

½”M

Brine tank connection

N

3/8”M

3/8”M

3/8”M

3/8”M

3/8”M

3/8”M

3/8”M

Rise pioe(out dia)

1.50D

1.05”OD

1.05”OD

1.05”OD

1.05”OD

1.05”OD

1.05”OD

1.05”OD
